HYSS - HYBRID SOLAR SYSTEM
Model program
MODULE DESCRIPTION
SHPT
(
S
= Solar,
HP
= Heat pump
T
= Tank)
190E
= Enamel tank of capacity 190 litres
200S
= Stainless steel tank of capacity 200 litres
Expansion vessels for solar/brine, heating system and
storage tank are included in the HYSS system. The
vessels are integrated into the module for the high SHPT.
The vessels are included in the delivery for the low SHPT,
to be mounted on the wall.
The heat pump has been tested at the Danish Technological
Institute and awarded the highest rating level (A+++)
specified by the European directive for ecodesign and
energy labelling requirements (EN14825).
Capacity regulated
(inverter) ground source
heatpump
Storage tank,
190 liter enamel
200 liter stainless steel
183cm
12cm
FE04 2-5,8kW
FE07 3,6-9,9kW
FE12 4-12,2kW
ulated
ound source
k,
mel
inless steel
W
dmini!
K
Imissmy iPadmini!
ALTOK
Low SHPT
60 cm
60 cm
60 cm
8 cm
187 cm
195 cm (ridge height 198 cm)
The cabinet has adjustable wheels at the rear
to make it easy and simple to place it in its
location.
Article number:
HYSS-model:
Weight (kg):
5507
Low SHPT-200S 4 KW
204
5508
Low SHPT-200S 7 KW
215
5509
Low SHPT-200S 12 KW
223
