HYSS - HYBRID SOLAR SYSTEM
19
DATA / CONTENTS
Heat pump:
Speed-controlled (inverter).
Cooling agent R410A
Power supply:
Single phase, 16 A
Circulation pumps: Highest energy class with
pulse width modulation (PWM)
Web-based control system
iPad mini – WiFi as display
Integrated COP/SCOP measurement equipment
with high accuracy
3 KW electrical heating element as back-up, solely in association
with service (not for use during peak load)
All modules have integrated functionality for solar energy, pool, and
extraction for passive cooling.
Filling valves for brine are included in the module.
10-year guarantee covers:
• heat pump compressor
• storage tank
• solar panels
183cm
12cm
Capacity regulated
(inverter) ground source
heatpump
Storage tank,
190 liter enamel
200 liter stainless steel
183cm
12cm
FE 04 2-5,8 kW
FE 07 3,6-9,9 kW
FE 12 4-12,2 kW
Imissmy iPadmini!
ALTOK
High SHPT
Lo
60 cm
60 cm
212 cm
8 cm
8 cm
187 cm
Article number:
HYSS-model:
Weight (kg):
5501
High SHPT-200S 4 KW
218
5502
High SHPT-200S 7 KW
230
5503
High SHPT-200S 12 KW
238
220 cm (ridge height 223 cm)
